626ZZ Miniature Deep Groove Ball Bearing 6x19x6mm Double Sealed Chrome Bearings 626 ZZ

The dimensions of the deep groove ball bearing 626ZZ are the same as the basic 626 bearing. It has

a bore diameter of 6 mm, an outer diameter of 26 mm, and a width of 6 mm.

The shields on the 626ZZ bearing are typically made of metal, such as steel or stainless steel, and are

placed close to the 626 bearing’s inner and outer rings. These shields act as protective barriers, preventing

harmful particles from entering the bearing and causing damage or premature wear.

Deep groove ball bearing 626ZZ is commonly used in applications where cleanliness and protection against

contaminants are crucial. It is often employed in precision instruments, electrical motors, automotive components,

and other machinery that operates in demanding or dusty environments.

Single row deep Groove Ball Bearings offer multiple options that serve a wide range of applications. The 'groove' is the depth of the raceway into which the balls fit, they typically consist of an Inner Ring, Outer Ring, Balls and Cage. Variants are available with Steel Shields, Rubber Seals (Contact/Non-Contact type), Snap-ring Grooves with Snap-rings, and a variety of Cage types.

These Bearings are designed for radial, axial, and also composite load applications, purpose of deep groove precision ball bearings is to reduce rotational friction and support radial and axial loads.Deep Groove Ball Bearings offer:

·Uni or bi-directional load carrying capability

·Very high-speed rotation

·Very good running accuracy

·Low noise and low friction torque
